5P-37G
Sharp; Osaka
- Country
- Japan
- Manufacturer / Brand
- Sharp; Osaka
- Year
- 1980/1981
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 147052
-
- alternative name: Hayakawa Electric Co.Ltd.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- 140CNB4
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Cassette-Recorder or -Player; Remote Control (with wire or wireless)
- Power type and voltage
- Line / Batteries (any type) / 220/ 12; 10 x 1,5 Volt
- Loudspeaker
- 4 Loudspeakers
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 5P-37G - Sharp; Osaka
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 602 x 337 x 223 mm / 23.7 x 13.3 x 8.8 inch
- Notes
-
Sharp 5P-37G
- 13,8 cm/5.5" 70° CRT B/W TV
- CCIR B/G standard tuner
- "Quick Start"
- Radio:
- LW: 150 - 285 kHz
- MW: 520 - 1.620 kHz
- FM: 87.5 - 108 MHz
- loc./DX switch
- Cass:
- tape counter
- APSS Auto Program Search System
- sleep timer
- frequency response up to 50 - 14.000 Hz
- 2 VU/batt./tuning meters
- 2 x 3.5 (6.2) W AF out
- 2 x 16 cm woofers
- 2 x 5 cm tweeters
- phono-in
- bass & treble control
- 2 telescopic antennas, ext. antenna in
- 5 ICs, 36 transistors, 40 diodes
- 2 x mic in, mix. mic in
- DIN terminal
- ext. speaker jacks, headphone jack.
- Net weight (2.2 lb = 1 kg)
- 10.6 kg / 23 lb 5.6 oz (23.348 lb)
- Price in first year of sale
- 998.00 DM
- Mentioned in
- -- Original prospect or advert ((D) Sharp TV-Audio 1980-81 - Mit Sharp durch die 80er Jahre)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
