Modern 6 Channels Mobile/Base Transceiver CBT-57
Sharp; Osaka
- Country
- Japan
- Manufacturer / Brand
- Sharp; Osaka
- Year
- 1975 ??
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 254759
-
- alternative name: Hayakawa Electric Co.Ltd.
Bild aus Sharp Service Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 12
- Semiconductors
- 2SC454 2SC458 unknown_tr unknown_tr 2SC458 2SC535 2SC460 2SC460 2SC454 2SC150 2SC608 unknown_tr 1N34A 1N34A
- Main principle
- Transceiver; ZF/IF 455 kHz
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 11.5-14.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
- Power out
- 2.2 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Modern 6 Channels Mobile/Base Transceiver CBT-57 - Sharp; Osaka
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 126 x 55 x 160 mm / 5 x 2.2 x 6.3 inch
- Notes
-
Six 27 MHz channels.
Base or Mobile transceiver operating in CB Band. Transmitter: Input 5 W. Receiver single superheterodyne with 1.0 µV sensitivity.
12 Transistors, 1 IC and 4 Diodes.
