GF-4000H
Sharp; Osaka
- Country
- Japan
- Manufacturer / Brand
- Sharp; Osaka
- Year
- 1975
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 129054
-
- alternative name: Hayakawa Electric Co.Ltd.
Ebay user immota_fides 130596278525
Ebay user immota_fides 130596278525
Ebay user immota_fides 130596278525
Ebay user immota_fides 130596278525
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 30
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 5 AM circuit(s) 8 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 110-240 / 6x1,5 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 3.3 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: GF-4000H - Sharp; Osaka
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 354 x 242 x 104 mm / 13.9 x 9.5 x 4.1 inch
- Notes
- ICs 2
- Net weight (2.2 lb = 1 kg)
- 4.9 kg / 10 lb 12.7 oz (10.793 lb)
- Price in first year of sale
- 530.00 DM
- Mentioned in
- Originál Sharp Service Unterlagen
- Literature/Schematics (1)
- -- Original-techn. papers.
- Literature/Schematics (2)
- Funk-Technik (FT) (14/1975, S. 440 / Neuvorstellung)
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
