• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1970 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 129792

• • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 28

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Tuned circuits
• 5 AM circuit(s)     7 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 42 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: GS-5600 - Sharp; Osaka

• Shape
• Tablemodel with Push Buttons.

• Notes
• Musik power 2 x 21 Watt, 2-Speed Stereo Ceramic Cartridge, speakers included.

• Mentioned in
• Original Sharp Service Unterlagen

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
