• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1983 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 310984

• • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110-120; 220-240 / D: 6 x 1,5 V Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 5.8 W (undistorted)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Stereo Radio - Tape Recorder GF-6464H - Sharp; Osaka

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 500 x 226 x 120 mm / 19.7 x 8.9 x 4.7 inch

• Notes

• The Sharp GF-6464H Stereo Radio - Tape Recorder is the same as the earlier Sharp GF-5454H FM/FM Stereo SW/MW/LW 4 Band Radio Recorder apart from colour and shape of the front of the cabinet..

• Net weight (2.2 lb = 1 kg)
• 3.9 kg / 8 lb 9.4 oz (8.59 lb)

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• - - Manufacturers Literature (Service Manual GF-6464H GF-6464E)

• Author
• Model page created by Egon Strampe. See "Data change" for further contributors.
