Optonica RT-9100H
Sharp; Osaka
- Country
- Japan
- Manufacturer / Brand
- Sharp; Osaka
- Year
- 1981
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 145222
-
- alternative name: Hayakawa Electric Co.Ltd.
Original propekt in 1981.
Aus den Hersteller-Unterlagen
Aus den Hersteller-Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player; Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 110/220/240 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Optonica RT-9100H - Sharp; Osaka
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 430 x 144 x 371 mm / 16.9 x 5.7 x 14.6 inch
- Notes
- Electronic Tape Processor with 2-Motor, Dual-Capstan Drive, Quartz PLL Servo Capstan Motor, APMS (Auto Programmable Music Selector), APSS (Auto Program Search System)and Remote Control.
Frequency Response 20 - 20000 Hz (FeCr, Metal).
Front Panel colour Silvermetallic.
- Net weight (2.2 lb = 1 kg)
- 12.5 kg / 27 lb 8.5 oz (27.533 lb)
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
