Portable Stereo Component System GF-7850E
Sharp; Osaka
- Country
- Japan
- Manufacturer / Brand
- Sharp; Osaka
- Year
- 1981 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 171273
-
- alternative name: Hayakawa Electric Co.Ltd.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 220 / 8 x 1,5 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 20 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Portable Stereo Component System GF-7850E - Sharp; Osaka
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 630 x 225 x 155 mm / 24.8 x 8.9 x 6.1 inch
- Notes
- Detachable speakers, Dolby NR system.
- Net weight (2.2 lb = 1 kg)
- 5.4 kg / 11 lb 14.3 oz (11.894 lb)
- Author
- Model page created by Bernhard Nagel. See "Data change" for further contributors.
