• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1973 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 127468

• • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 14

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 5.6 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: RDX-708 - Sharp; Osaka

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 400 x 390 x 270 mm / 15.7 x 15.4 x 10.6 inch

• Notes
• Stereo Tonbandgerät für 120-240 Volt und 50Hz.

• Net weight (2.2 lb = 1 kg)
• 15.5 kg / 34 lb 2.3 oz (34.141 lb)

• Mentioned in
• Original Sharp Service Unterlagen

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
