BP-102A

Sharp; Osaka

  • Year
  • 1968 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 124667
    • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Tuned circuits
  • 5 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 2 × 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
  • Power out
  • 0.16 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: BP-102A - Sharp; Osaka
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 68 x 100 x 31 mm / 2.7 x 3.9 x 1.2 inch
  • Notes
  • Dieses Gerät gab es in verschiedenen Farben.
  • Net weight (2.2 lb = 1 kg)
  • 0.164 kg / 0 lb 5.8 oz (0.361 lb)
  • Mentioned in
  • Original Sharp Service Unterlagen
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.

 Collections | Museums | Literature

 Forum

Forum contributions about this model: Sharp; Osaka: BP-102A

Threads: 1 | Posts: 1

Abweichende Transistorbestückung: 2SA354  2SA353  2SA12  2SB77  2SB77  2SB77

Peter Kovacs, 01.Nov.10
