• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1965 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 221288

• • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 110; 120; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: RT-816X Ch= RT 816 - Sharp; Osaka

• Shape
• Book-shelf unit.

• Notes
• 8 Spur 2 Kanal Stereo Wiedergabegerät.

• Mentioned in
• Sharp Service Unterlagen

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
