Small Portable BP-156 III (3)

Sharp; Osaka

Data
Forum
Pictures
Collections

  • Year
  • 1970 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 224189
    • alternative name: Hayakawa Electric Co.Ltd.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 5 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 2 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Small Portable BP-156 III - Sharp; Osaka
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 61 x 107 x 35 mm / 2.4 x 4.2 x 1.4 inch
  • Notes

  • This is identical to the BP-156, but is clearly a version for the American market only.
    Slightly different model panel.

    Made in Singapore

  • Net weight (2.2 lb = 1 kg)
  • 0.170 kg / 0 lb 6 oz (0.374 lb)
  • Author
  • Model page created by Stephen Higgins. See "Data change" for further contributors.
