• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1970 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 221004

• • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 1.3 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Solid State Tape Recorder RD-514E Ch= RD 514 - Sharp; Osaka

• Shape
• Tablemodel, low profile (big size).

• Notes
• Zwei Spur Mono Tonbandgerät, zwei Geschwindigkeiten 9,5 und 4,8 cm/sec.

• Mentioned in
• Sharp Service Unterlagen

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
