ST-3636 H

• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1977/1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 125531

• • alternative name: Hayakawa Electric Co.Ltd.

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: ST-3636 H - Sharp; Osaka

• Shape
• Book-shelf unit.

• Notes
• HiFi-Stereo-Tuner. Bandbreite und M-Filter schaltbar; Ausgangsspannung fest und variabel.

• Source of data
• Handbuch VDRG 1977/1978

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
