• Country
• Japan

• Manufacturer / Brand
• Sharp; Osaka

• Year
• 1982/1983

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 139420

• • alternative name: Hayakawa Electric Co.Ltd.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110-120; 220-240 / 8 x 1,5 Volt

• Loudspeaker
• 4 Loudspeakers / Ø 12 cm = 4.7 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Stereo-Radio Tape-Recorder GF-7500H - Sharp; Osaka

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 550 x 200 x 140 mm / 21.7 x 7.9 x 5.5 inch

• Notes
• Stereo-Radio Tape-Recorder GF-7500H.
  Radio: Frequenzbereich UKW 87,6 bis 108 MHz, SW 5,95 bis 18 MHz, MW 529 bis 1620 kHz, LW 150 bis 285 kHz, Mono/Stereo-Schalter, Teleskopantenne.
  Kassettenrecorder: Soft-Touch Operation, CrO2/Metal-Umschaltung, Sound Level Meter durch LED, Tape Counter.
  Power: Volume-Balance-Ton, EXT MIC-Input, 5-Pol. DIN-Buchse, zusätzliche Lautsprecher 3 bis 8 Ohm anschließbar.

• Net weight (2.2 lb = 1 kg)
• 4.2 kg / 9 lb 4 oz (9.251 lb)

• Price in first year of sale
• 4,990.00 ATS

• Mentioned in
• -- Original prospect or advert (Funkberaterkatalog 1982)

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
