Stereo Receiver SA-103H
Sharp; Osaka
- Country
- Japan
- Manufacturer / Brand
- Sharp; Osaka
- Year
- 1983 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 303661
-
- alternative name: Hayakawa Electric Co.Ltd.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 110; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 90 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Receiver SA-103H - Sharp; Osaka
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 330 x 106 x 291 mm / 13 x 4.2 x 11.5 inch
- Notes
-
Stereo tuner/amplifier with 7 ICs, 24 transistors, 2 FETs, 28 diodes and 4 LEDs. Inputs for phono, tape and aux.
Amplifier :
- Music power output : 2 x 45W into 4Ω 0.8% THD
- Continuous power output : 2 x 30W into 4Ω 0.8% THD
- Frequency response : 20Hz - 30kHz
Tuner :
- FM frequency range : 87.6 - 108 MHz
- MW frequency range : 520 - 1620 khz
- LW frequency range : 148.5 - 370 kHz
See matching components Sharp RT-103H stereo cassette deck and Sharp RP-103H stereo turntable.
- Net weight (2.2 lb = 1 kg)
- 4.1 kg / 9 lb 0.5 oz (9.031 lb)
- Mentioned in
- - - Manufacturers Literature (Operation manual for the SA-103H/HB)
- Author
- Model page created by Manfred Rathgeb. See "Data change" for further contributors.
