Optonica SM-5100H

Sharp; Osaka

Data
Forum
Pictures
Collections

  • Year
  • 1980
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 132657
    • alternative name: Hayakawa Electric Co.Ltd.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 16
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 110-240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 90 W (150 W max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Optonica SM-5100H - Sharp; Osaka
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 75 x 382 mm / 16.9 x 3 x 15 inch
  • Notes

  • Optonica SM-5100H

    Stereoverstärker. 3 IC; Sinus-Ausgangsleistung (1.000 Hz) an 4 Ω, 2 x 45 Watt bei 0,05 % Klirr,  Musikleistung 2 x 75 Watt, Loudness, High Filter 7000 Hz/6 dB schaltbar, Low Filter (Subsonic) 30 Hz/ 6 dB schaltbar, Mute.
    Farbe Silber.

    Passender Tuner: ST 5100H

  • Net weight (2.2 lb = 1 kg)
  • 8 kg / 17 lb 9.9 oz (17.621 lb)
  • Source of data
  • -- Original prospect or advert
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
