Double Cassette Deck D-480

Sherwood, Chicago

Data
Forum
Pictures
Collections

  • Year
  • 1983 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 275241

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Double Cassette Deck D-480 - Sherwood, Chicago
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 440 x 125 x 245 mm / 17.3 x 4.9 x 9.6 inch
  • Notes

  • Sherwood Frontloading Double Cassette Deck Model D-480.
    Auto Reverse, Auto Tape Selector
    Dolby B, C NR, HX Pro
    Digilink M Remote Control
    High Speed Dubbing
    CD Sync
    Headphone Jack

    Power Requirements:
    USA & Canada Model - 120VAC
    Australia & Europe Model - 220/230/240VAC
    Other Countries - 110/220VAC (Voltage Selector Switch)
    AC Outlet - 120VAC 60Hz 1A max. 100 Watts (Regional Option)
    Power Consumption 120VAC 60Hz - max. 16 Watts






  • Net weight (2.2 lb = 1 kg)
  • 5.8 kg / 12 lb 12.4 oz (12.775 lb)
  • Mentioned in
  • - - Manufacturers Literature (Instruction Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
