Crosley 225
SIARE (-Crosley); Piacenza
- Country
- Italy
- Manufacturer / Brand
- SIARE (-Crosley); Piacenza
- Year
- 1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 144821
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 350 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
- Power out
- 3.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Crosley 225 - SIARE -Crosley; Piacenza
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 550 x 300 x 230 mm / 21.7 x 11.8 x 9.1 inch
- Net weight (2.2 lb = 1 kg)
- 9.6 kg / 21 lb 2.3 oz (21.145 lb)
- Source of data
- Guida Pratica Antique Radio II (2000)
- Author
- Model page created by Alessandro De Poi. See "Data change" for further contributors.
