Alpha FC 351 Körting Ch= 8
Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Country
- Germany
- Manufacturer / Brand
- Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Year
- 1979 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 198453
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900/5500 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- -Loudspeaker incorporated, but system not known.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Alpha FC 351 Körting Ch= 8 - Siemens & Halske, -Schuckert
- Shape
- Tablemodel, low profile (big size).
- Notes
- Siemens FC 351 mit Koerting Chassis 8 Ch= 8
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Holger Ortmann. See "Data change" for further contributors.
