AM/FM - Antennenprüfgerät SAM372St

• Country
• Germany

• Manufacturer / Brand
• Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München

• Year
• 1967

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 96584

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios)

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: AM/FM - Antennenprüfgerät SAM372St - Siemens & Halske, -Schuckert

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 420 x 310 x 200 mm / 16.5 x 12.2 x 7.9 inch

• Notes
• Tragbares Antennenprüfgerät mit Breitbandskala und Meßinstrument für Pegelwerte, Akku oder Batteriebetrieb, war auch ohne Stereozusatzteil SAZ7156 lieferbar.

• Net weight (2.2 lb = 1 kg)
• 9.8 kg / 21 lb 9.4 oz (21.586 lb)

• Mentioned in
• Funkschau (Heft 12 1967)

• Author
• Model page created by a member from A. See "Data change" for further contributors.

• Other Models

• Here you find 2523 models, 2120 with images and 1333 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
