• Country
• Germany

• Manufacturer / Brand
• Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München

• Year
• 1977/1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 78330

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 24

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220 / 6×1,5 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 12 cm = 4.7 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Club RM706 - Siemens & Halske, -Schuckert

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 443 x 290 x 115 mm / 17.4 x 11.4 x 4.5 inch

• Notes
• ICs: 6.
  Stereo-NF-Verstärker mit 2 Endstufen je 3 W. Zwei eingebaute Mikrofone, Eingänge für zwei Mikrofone, Phono und Kopfhörer. Anschlüsse für zwei externe LS. Stromversorgung zusätzlich mit 9-Volt-Adapter möglich.

• Net weight (2.2 lb = 1 kg)
• 5.7 kg / 12 lb 8.9 oz (12.555 lb)

• Source of data
• Handbuch VDRG 1977/1978

• Author
• Model page created by Peter Böhm. See "Data change" for further contributors.
