• Country
• Germany

• Manufacturer / Brand
• Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München

• Year
• 1959 ??

• Category
• RF (Radio Frequency-) Amplifier

• Radiomuseum.org ID
• 267606

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• E88CC

• Main principle
• Radio Frequency Amplification only

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Powered by external power supply or a main unit.

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: F I - Antennenverstärker-Einsatz SAVE 334 W - Siemens & Halske, -Schuckert

• Shape
• Chassis only or for «building in»

• Notes

• Frequenzbereich 47 bis 68 MHz (Kanal 2 bis 4) jeweils nur für einen Fernsehkanal im Band I

• Mentioned in
• -- Original-techn. papers. (Aus Montageanleitung)

• Author
• Model page created by Walter Haring. See "Data change" for further contributors.
