Großsuper 14W
Siemens Elektrizitätserzeugnisse AG, Zürich
- Country
- Switzerland
- Manufacturer / Brand
- Siemens Elektrizitätserzeugnisse AG, Zürich
- Year
- 1943/1944
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 13534
-
- alternative name: Siemens EAG; Schweiz
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 471 kHz
- Tuned circuits
- 6 AM circuit(s)
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Großsuper 14W - Siemens
- Dimensions (WHD)
- 600 x 467 x 287 mm / 23.6 x 18.4 x 11.3 inch
- Notes
- Import aus Deutschland (siehe dort),Vertrieb in CH durch Albiswerk.
- Net weight (2.2 lb = 1 kg)
- 18 kg / 39 lb 10.4 oz (39.648 lb)
- Price in first year of sale
- 790.00 SFr
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Circuit diagram reference
- Thali-Schemasammlung und Tungsram-Röhrenbestückung.
