Konzertmeister RP93
Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Country
- Germany
- Manufacturer / Brand
- Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Year
- 1967
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 165857
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Number of Transistors
- 10
- Semiconductors
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Konzertmeister RP93 - Siemens & Halske, -Schuckert
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 1016 x 717 x 370 mm / 40 x 28.2 x 14.6 inch
- Notes
- Der Stereodekoder enthält zusätzlich 3 Transistoren und 8 Dioden. Plattenwechsler: Philips AG 1035 mit Kristallsystem AG 3306.
- Net weight (2.2 lb = 1 kg)
- 32 kg / 70 lb 7.8 oz (70.485 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Heinz Hirsch † 28.2.10. See "Data change" for further contributors.
