LMKU-Antennenprüfgerät SAM316W
Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Country
- Germany
- Manufacturer / Brand
- Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Year
- 1956 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 114025
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Number of Transistors
- Semiconductors
- OA150
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Power out
- 0.5 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: LMKU-Antennenprüfgerät SAM316W - Siemens & Halske, -Schuckert
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 560 x 280 x 250 mm / 22 x 11 x 9.8 inch
- Notes
- Dient zur Messung an Antennen und -anlagen.
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Josef Loidl. See "Data change" for further contributors.
