Mikrofonverstärker Elv.34
Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Country
- Germany
- Manufacturer / Brand
- Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Year
- 1930
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 115708
- Number of Tubes
- 2
- Main principle
- Audio-Amplification; 2 AF stage(s)
- Wave bands
- - without
- Power type and voltage
- Storage and/or dry batteries / 4 & 200 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Mikrofonverstärker Elv.34 - Siemens & Halske, -Schuckert
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 260 x 173 x 150 mm / 10.2 x 6.8 x 5.9 inch
- Notes
-
RC-Kopplung. Verstärkung einstellbar. Wurde zur Vorverstärkung für Stab-, Kreuz- und Bändchenmikrofone, z.B. dem Siemens-Bändchenmikrofon Elm.24 eingesetzt.
Preis 1931/32 ohne Röhren.
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- Price in first year of sale
- 180.00 RM
- Source of data
- -- Collector info (Sammler)
- Mentioned in
- Radio-Schnorr-Katalog Nr.53 1931/32
- Author
- Model page created by Bernhard Nagel. See "Data change" for further contributors.
