- Country
- Germany
- Manufacturer / Brand
- Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Year
- 1929
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 76394
- Number of Tubes
- 5
- Main principle
- TRF with regeneration; 2 AF stage(s)
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast and LongWave in ONE range.
- Power type and voltage
- Alternating Current supply (AC) / 110-250 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: Rfe32a - Siemens & Halske, -Schuckert
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 490 x 280 x 260 mm / 19.3 x 11 x 10.2 inch
- Notes
-
Identisch mit Siemens Rfe32, aber Gehäuse Holz + Presstoff.
- Author
- Model page created by Patrice Zeissloff. See "Data change" for further contributors.
