Stereo System RS175R4
Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Country
- Germany
- Manufacturer / Brand
- Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München
- Year
- 1991 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 145312
Bild aus Siemens Service Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 48
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- CD-Player, -Writer, MD, MOD (audio)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Various materials
- from Radiomuseum.org
- Model: Stereo System RS175R4 - Siemens & Halske, -Schuckert
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 275 x 270 x 250 mm / 10.8 x 10.6 x 9.8 inch
- Notes
- ICs: 9
Kleine Kompaktanlage mit Cassettenrecorder und CD-Player. Musikleistung: 2× 5 Watt.
- Net weight (2.2 lb = 1 kg)
- 10.4 kg / 22 lb 14.5 oz (22.907 lb)
- Mentioned in
- Original Siemens Service Unterlagen
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
