Telegrafie-Empfangstastgerät FSE30

• Country
• Germany

• Manufacturer / Brand
• Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München

• Year
• 1964

• Category
• Morse-Equipment & TTY, RTTY, TDD etc.

• Radiomuseum.org ID
• 107338

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• DG7-52A

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• RF Converter/Adapter (not voltage converter); ZF/IF 30 kHz

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Telegrafie-Empfangstastgerät FSE30 - Siemens & Halske, -Schuckert

• Shape
• Boatanchor (heavy military or commercial set >20 kg).

• Dimensions (WHD)
• 463 x 160 x 385 mm / 18.2 x 6.3 x 15.2 inch

• Notes

• ZF-Fernschreibkonverter für Empfänger E311. Betriebsarten F1 (max. 200 Bd), F4 (max. 3500 Bd) und F6 (max. 75 Bd). Diversity-Option.

• Net weight (2.2 lb = 1 kg)
• 15 kg / 33 lb 0.6 oz (33.04 lb)

• Price in first year of sale
• 5,806.00 DM

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
