Carioca SI 4201 A /00
Siera; (where?)
- Country
- Italy
- Manufacturer / Brand
- Siera; (where?)
- Year
- 1967 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 294377
- Number of Tubes
- 3
- Number of Transistors
- 2
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110-127; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Carioca SI 4201 A /00 - Siera; where?
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 360 x 170 x 115 mm / 14.2 x 6.7 x 4.5 inch
- Notes
-
- Gruppo "front-end" FM a transistors al germanio con due AF121;
- Senza trasformatore di alimentazione e diodo al silicio tipo BY127.
- Net weight (2.2 lb = 1 kg)
- 2.5 kg / 5 lb 8.1 oz (5.507 lb)
- Author
- Model page created by Giuseppe Feniello. See "Data change" for further contributors.
