S256V
Siera; Belgien
- Country
- Belgium
- Manufacturer / Brand
- Siera; Belgien
- Year
- 1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 150187
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and more than two Short Wave bands.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21.5 cm = 8.5 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: S256V - Siera; Belgien
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 440 x 325 x 225 mm / 17.3 x 12.8 x 8.9 inch
- Notes
- Kind of Farm Radio. Short Wave: 5 bands. Vibrator for +B. Dial lamps: 2x 6,3V/0,3A.
- Net weight (2.2 lb = 1 kg)
- 9.6 kg / 21 lb 2.3 oz (21.145 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
