• Country
• Belgium

• Manufacturer / Brand
• Siera; Belgien

• Year
• 1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 206596

• Number of Tubes
• 11

• Valves / Tubes
• ECC85 ECH81 EBF80 EF85 EM80 EABC80 EBC41 EL84 EL84 EL84 EL84

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 240 Volt

• Loudspeaker
• 3 Loudspeakers

• Power out
• 3 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: SA3041A - Siera; Belgien

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 920 x 720 x 395 mm / 36.2 x 28.3 x 15.6 inch

• Notes
• Record changer=Philips AG1000.

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by Jacques Deseyne. See "Data change" for further contributors.

• Other Models

• Here you find 456 models, 414 with images and 188 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Siera; Belgien
