All Wave Transistor 7TS-190
Silver (Brand) - Shin-Shirasuna Electric Corp; Nagoya
- Country
- Japan
- Manufacturer / Brand
- Silver (Brand) - Shin-Shirasuna Electric Corp; Nagoya
- Year
- 1962 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 206915
-
- alternative name: Shin-Shirasuna Electric Corp. || Shirasuna Denki Mfg. Co. Ltd. || Shirasuna (Shin) Electric Corp.
- Brand: Plata (brand)
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Dry Batteries / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm
- Power out
- 0.12 W (0.18 W max.)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: All Wave Transistor 7TS-190 - Silver Brand - Shin-Shirasuna
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 7.25 x 4.25 x 2.25 inch / 184 x 108 x 57 mm
- Notes
- Silver All Wave Transistor 7TS-190, 3-Band 7-Transistor Portable Radio;
- Net weight (2.2 lb = 1 kg)
- 1 lb 14 oz (1.875 lb) / 0.851 kg
