• Country
• United States of America (USA)

• Manufacturer / Brand
• Silver - Marshall; Chicago, IL

• Year
• 1932

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 18921

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• 24 27 27 35 or 51 35 or 51 27 27 47 47 80

• Main principle
• Superheterodyne (common); Screengrid 1926-1935

• Tuned circuits
• 8 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• from Radiomuseum.org
• Model: Q [type 1] - Silver - Marshall; Chicago, IL

• Notes
• Tuning meter; push-pull af output stage.

• External source of data
• E. Erb 3-907007-36-0

• Circuit diagram reference
• Die «Thali Schemasammlung» führt das Modell.

• Literature/Schematics (1)
• Rider's Perpetual, Volume 4 = ca. 1934 and before
