• Country
• Italy

• Manufacturer / Brand
• Simplex Radio; Torino

• Year
• 1955 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 292046

• Number of Tubes
• 5

• Valves / Tubes
• 6BE6 6BA6 6AT6 50B5 35W4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 153 - Simplex Radio; Torino

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 290 x 180 x 140 mm / 11.4 x 7.1 x 5.5 inch

• Notes

• Telaio Kosmophon (Eterphon gruppo Italradio)

• Net weight (2.2 lb = 1 kg)
• 2.6 kg / 5 lb 11.6 oz (5.727 lb)

• Author
• Model page created by Alberto Ammendola. See "Data change" for further contributors.
