• Country
• Canada

• Manufacturer / Brand
• Simpson Co. Ltd., The Robert (Simpson's); (where?)

• Year
• 1950 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 294288

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 9

• Valves / Tubes
• 6BA6 6BE6 6BA6 6AT6 or 6AV6 6U5 6J5 6V6GT 6V6GT 5Y3GT

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 110 to 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Serenader 5002 - Simpson Co. Ltd., The Robert

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 31.25 x 32 x 15.25 inch / 794 x 813 x 387 mm

• Notes

• The Serenader 5002 is a 9-tube combination radio / record changer console with eye tube. Covers standard broadcast and 9 to 18 MHz shortwave. For 25 or 60 Hz depending on nameplate rating. Made by Dominion Electrohome Ltd for Simpsons.

• Literature/Schematics (1)
• Radio College of Canada (RCC) (Supplement 23 pages 26 and 30.)

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
