Ancar
Skreibson; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Skreibson; Barcelona
- Year
- 1963 ??
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 333062
- Number of Tubes
- 3
- Number of Transistors
- 2
- Main principle
- Superheterodyne (common); ZF/IF 450 kHz; 3 AF stage(s)
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 1.5 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Ancar - Skreibson; Barcelona
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 180 x 180 x 80 mm / 7.1 x 7.1 x 3.1 inch
- Notes
-
Negativo al chasis.
- Net weight (2.2 lb = 1 kg)
- 1.834 kg / 4 lb 0.6 oz (4.04 lb)
- Author
- Model page created by Jesús Casado Arriazu. See "Data change" for further contributors.
