• Year
  • 1969
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 198889

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 8
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)
  • Tuned circuits
  • 8 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 6 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AU-17 - Skreibson; Barcelona
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 186 x 65 x 182 mm / 7.3 x 2.6 x 7.2 inch
  • Notes
  • Adaptable a positivo o negativo a masa.
    Salida para altavoz de 4 ohmios.
  • Net weight (2.2 lb = 1 kg)
  • 1.7 kg / 3 lb 11.9 oz (3.744 lb)
  • Literature/Schematics (1)
  • -- Schematic
