Holymat 33
Skreibson; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Skreibson; Barcelona
- Year
- 1973
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 290947
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 5
- Semiconductors
- BF194 BF194 BC149 BC148 BC148 TBA460 TBA810 unknown_IC TCA610B AA119 SFD186 SD60 1N4161
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 6 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Holymat 33 - Skreibson; Barcelona
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 180 x 49 x 140 mm / 7.1 x 1.9 x 5.5 inch
- Notes
-
El integrado desconocido aparece en el manual como 580X0030 que a su vez corresponde con el código de la pieza de repuesto. Probablemente lo ocultaran para evitar la copia..
- Net weight (2.2 lb = 1 kg)
- 1.575 kg / 3 lb 7.5 oz (3.469 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
