• Country
• Japan

• Manufacturer / Brand
• Soar Corporation; Hanishinagun

• Year
• 1978

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 328427

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 11

• Semiconductors
• 2SK44 2SA608 2SC536 2SC536 2SC536 2SK44 2SK44 2SK44 2SC536 2SC536 2SC536 LM348 LD130 MSM561 MAN74 MAN74 MAN74 MAN74

• Wave bands
• - without

• Power type and voltage
• Batteries / addl. power jack / AA: 4 x 1,5 / 6 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Digital Multimeter ME-521 [/D /E /F /DEF] - Soar Corporation; Hanishinagun

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 95 x 155 x 44 mm / 3.7 x 6.1 x 1.7 inch

• Notes

• Soar Corporation, Digital Multimeter ME-521

  Led 3 digit (Max. reading 999 or -999)

  Measures: V (AC/DC), mA (AC/DC), Ohms (kΩ), in 4 ranges (1-10-100-1000),



• Net weight (2.2 lb = 1 kg)
• 0.3 kg / 0 lb 10.6 oz (0.661 lb)

• Mentioned in
• Electronics Australia, February 1978

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
