• Country
• Japan

• Manufacturer / Brand
• Soar Corporation; Hanishinagun

• Year
• 1978 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 328518

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 3

• Semiconductors
• unknown_tr_NPN unknown_tr_PNP unknown_tr_FET ICL7106 TL061 CD4001 CD4077 ICL8069 ICL8211 1N4001 1S1588

• Wave bands
• - without

• Power type and voltage
• Batteries / addl. power jack / pp3: 1 x 9 / 9 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Digital Multimeter ME-unknown1 - Soar Corporation; Hanishinagun

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Notes

• Soar Corporation, Digital Multimeter ME-unknown1

  LCD 3-½ digit (Max. reading 1999 or -1999)

  Measures: V (AC/DC), mA (AC/DC), Ohms, in 5 ranges

  This schematic was originally stapled to the Soar ME-522 manual but does not correspond with the spare parts list.





• Net weight (2.2 lb = 1 kg)
• 0.3 kg / 0 lb 10.6 oz (0.661 lb)

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.

• Other Models

• Here you find 29 models, 23 with images and 16 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Soar Corporation; Hanishinagun
