612AG/3
Sobell Ind., Slough
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Sobell Ind., Slough
- Year
- 1951
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 144154
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 205-245 Volt
- Loudspeaker
- 2 Loudspeakers
- from Radiomuseum.org
- Model: 612AG/3 - Sobell Ind., Slough
- Shape
- Console with any shape - in general
- Notes
- Delux version of 512ACG/3, fitted with magic eye & 3 speed changer.
- Source of data
- -- Schematic
- Circuit diagram reference
- Radio and TV Servicing books (R&TVS) book
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1068)
- Author
- Model page created by Keith Staines. See "Data change" for further contributors.
