• Country
• Belgium

• Manufacturer / Brand
• Radio-Bourse (Rexola, Rex); Bruxelles

• Year
• 1935 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 122759

• • Brand: Rexola

• Number of Tubes
• 5

• Valves / Tubes
• 6A7 6D6 75 42 80

• Main principle
• Superheterodyne (common); ZF/IF 458 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 145; 220; 245 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch

• Power out
• 3.2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Rexola Inconnu Unknown - Radio-Bourse Rexola, Rex;

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 383 x 439 x 265 mm / 15.1 x 17.3 x 10.4 inch

• Net weight (2.2 lb = 1 kg)
• 10.1 kg / 22 lb 3.9 oz (22.247 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Jozef Brughmans †. See "Data change" for further contributors.
