• Country
• Germany

• Manufacturer / Brand
• Sommerkamp

• Year
• 1973 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 349169

• • alternative name: Sommerkamp El. Schweiz

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• B5870S

• Number of Transistors
• 10

• Semiconductors

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Frequency Counter YC-355D - Sommerkamp

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 210 x 80 x 270 mm / 8.3 x 3.1 x 10.6 inch

• Notes

• TTL Frequency Counter, two ranges (0 - 35 MHz and 30 - 200 MHz). Made by Yaesu.





• Net weight (2.2 lb = 1 kg)
• 3.150 kg / 6 lb 15 oz (6.938 lb)

• Author
• Model page created by Xavier Motti. See "Data change" for further contributors.
