Ukendt - unknown
Sonofon; Denmark
- Country
- Denmark
- Manufacturer / Brand
- Sonofon; Denmark
- Year
- 1935 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 341890
-
- alternative name: Prytz & Berthelsen
Schallstoff vermutlich nachgerüstet.
Wellenschalter Lang-, Mittelwelle, Pickup
- Number of Tubes
- 3
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); 1 AF stage(s)
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- AC/DC-set / 220 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet. / Ø 21 cm = 8.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Ukendt - unknown - Sonofon; Denmark
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 340 x 320 x 210 mm / 13.4 x 12.6 x 8.3 inch
- Notes
-
Mit Tonabnehmer-Eingang (Grammophon).
- Author
- Model page created by Wilhelm Siepe. See "Data change" for further contributors.
