Television Receiver 613

• Country
• United States of America (USA)

• Manufacturer / Brand
• Sonora Radio & Telev. Corp.; Chicago (IL)

• Year
• 1957 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 272227

• • alternative name: Sonora Electric Phono

• Picture
• Schematics

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• 3BC5 5X8 5AN8 5U8 6AW8 6AW8 3DT6 6CM7 12DQ6 12AX4GTA 1X2B 17AVP4A

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• from Radiomuseum.org
• Model: Television Receiver 613 - Sonora Radio & Telev. Corp.;

• Shape
• Tablemodel, low profile (big size).

• Mentioned in
• Photofact Folder, Howard W. SAMS (Set 353, Folder 13, Date 4-57)

• Author
• Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
