• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1981

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 181129

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 80 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: FM Stereo/FM-AM Receiver STR-V45L - Sony Corporation; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 430 x 120 x 130 mm / 16.9 x 4.7 x 5.1 inch

• Notes

• Sony FM Stereo/FM-AM Receiver STR-V45L,
  2 x 40 Watt Sinusleistung an 8 Ohm.



• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Klemens Rhode. See "Data change" for further contributors.
