• Country
• Spain

• Manufacturer / Brand
• Sony España; Hispano Sony; Kosmos Eléctrica; Las Franquesas del Vallés

• Year
• 1974 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 110561

• • alternative name: Hispano Sony S.A.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors
• 2SC710 2SC633 2SB405 CX-016 1T22 1T23 1T26 1S330 10D-2

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110; 220 / C: 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 1.5 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Cassette Corder AM-FM CF-300 - Sony España; Hispano Sony;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 287 x 62 x 217 mm / 11.3 x 2.4 x 8.5 inch

• Notes

• Véase también el modelo de Sony Tokyo: CF-300

  Semiconductor list: only once per type.

• Net weight (2.2 lb = 1 kg)
• 3.2 kg / 7 lb 0.8 oz (7.048 lb)

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Jordi Cardona Serra. See "Data change" for further contributors.
