Compact Disc Deck Receiver HCD-G1
Sony Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sony Corporation; Tokyo
- Year
- 1997 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 326273
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Other Combination - see Notes
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 80 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Compact Disc Deck Receiver HCD-G1 - Sony Corporation; Tokyo
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 355 x 325 x 330 mm / 14 x 12.8 x 13 inch
- Notes
-
Sony, Compact Disc Deck Receiver HCD-G1
- Amplifier 40 W + 40 W
- CD Player
- Two Tape Deck
- Imput Phono
- Output hear
- Net weight (2.2 lb = 1 kg)
- 8 kg / 17 lb 9.9 oz (17.621 lb)
- Author
- Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.
