Compact Disc Player CDP-FLX1

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1991 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 316474

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 100; 220-230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Compact Disc Player CDP-FLX1 - Sony Corporation; Tokyo
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 141 x 60 x 220 mm / 5.6 x 2.4 x 8.7 inch
  • Notes

  • A small table top stereo hi-fi compact disc player with remote control (RM-DD1), the main component in the Sony FLX-1 Personal CD System which includes two Sony SA-FLX1 Active Loudspeakers. High Density Linear Converter, Direct Digital Sync. With clock/alarm. Mini jacks for variable Line Out and Phones, and for Line In.

    Specification
    Outputs
    LINE OUT (VARIABLE)
    (mini-jack)    		 Output level max. 2 V (at 50 kΩ)
    Load impedance over 50 kΩ
    PHONES
    (mini-jack)    		 Output level max. 10 mW
    Load impedance 32 Ω
    Inputs
    LINE IN
    (mini-jack)    		 Input impedance 2 kΩ

    Versions/Power requirements
    AEP /  220 V - 230 V AC 50/60 Hz
    Japan /  100V AC 50/60Hz

    Power consumption 9 W

  • Net weight (2.2 lb = 1 kg)
  • 1.1 kg / 2 lb 6.8 oz (2.423 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Service Manual Sony CDP-FLX1)
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
